ACM Panel Configurator
Configure your panels. Pricing updates automatically.
Configuration
Choose thickness, size, color, and quantity.
Select panel thickness.
Enter width and length for the flat center face. Allowed: 12–62" wide, 12–190" long, up to 16 returns (first four sides default to Front, Back, Left, Right at 90°).
Tray sides (returns)
Use Add side or Add fold on this edge to build returns, then set height and angle for each row. Reverse bend flips the bend direction.
- Side 1
Edge
Front
- Side 2
Edge
Back
- Side 3
Edge
Left
- Side 4
Edge
Right
Restores the default four-sided tray; width and length are unchanged.
Select a standard Alfrex FR finish or custom color match. Series below follow the standard finishes catalog.
Order color swatches
Request physical finish samples to review color and appearance under your lighting before you order panels. Contact us with the finish names or JY codes you need and your ship-to address; we will confirm availability and how samples are provided.
2 coat solids
30 Year Finish Warranty
Classic White
JY-5195
Bone White
JY-5165
Ascot White
JY-5110
Alabaster
JY-6165
Oyster
JY-5125
Castle Gray
JY-6160
Sea Wolf
JY-6175
Dove Gray
JY-6120
Slate Gray
JY-6145
Fashion Gray
JY-6130
Greyhound
JY-6155
Dark Gray
JY-6140
Charcoal
JY-6150
Bronze
JY-6180
Black
JY-6220
Midnight Black
JY-6230
Vivid solids*
20 Year Limited Finish Warranty
Signal Blue
JY-7110
2 coat solid
Harmony Blue
JY-7115
2 coat solid
Vibrant Red
JY-7120
3 coat solid
Patriot Red
JY-7140
3 coat solid
RON Red
JY-7150
3 coat solid
2 coat micas
30 Year Finish Warranty. Micaceous finishes can appear directional under different viewing angles and lighting.
Anodic Clear Mica
JY-2510
Exotic Silver Mica
JY-2520
Silversmith
JY-2515
Gray Silver Mica
JY-2530
Pewter Mica
JY-2540
MZG Gray Mica
JY-2535
Champagne Mica
JY-2550
Medium Bronze Mica
JY-2560
Driftwood Mica
JY-2555
Copper Penny Mica
JY-2570
Hazelnut Mica
JY-2575
New Age Dark Bronze Mica
JY-2580
3 coat metallics
30 Year Finish Warranty
Bright Silver Metallic
JY-3510
Champagne Metallic
JY-3520
PEX Pewter Metallic
JY-3540
JLR Gray Metallic
JY-3550
Anthracite Silver Metallic
JY-3560
Graphite Metallic
JY-3530
Metal series
20 Year Finish Warranty
Faux Zinc Lite
JY-M130
Faux Zinc
JY-M120
Faux Zinc Graphite
JY-M110
Tile Corten
JY-M140
Wood series
20 Year Finish Warranty
Teak
JY-W120
Golden Oak
JY-W140
Dark Walnut
JY-W150
Natural zinc series*
*Non-stocking item subject to minimum quantities. Bond integrity warranty only.
Blue Grey
JY-Z110
Graphite Grey
JY-Z100
Specialty series*
Non-stocking / made to order — confirm availability and lead time with your quote.
Hairline Clear
JY-H100
Mirror
JY-A160
Custom colors
To begin the custom color match process, send a physical sample (preferred), a coating manufacturer paint code, or a reference such as a Pantone number, with your performance requirements. Perfect matches are not always possible due to substrate, paint system, and process differences — contact us for specifics.
Custom color match
Custom (MOQ)
On-screen swatches are approximations. Final color varies by lighting, viewing angle, and production lot.
Selected: Classic White (JY-5195)
Number of panels.
Flat panel preview
Rectangular sheet — color and size only (no fold).
62" × 96" · Classic White
Fold & bend preview
Drag to rotate; use +, −, and 1× to zoom. Labels show the flat center and each return; stacked folds may repeat on the same edge.
62" × 96" tray · Classic White
Returns
- Side 1 · Front · 1" @ 90°
- Side 2 · Back · 1" @ 90°
- Side 3 · Left · 1" @ 90°
- Side 4 · Right · 1" @ 90°
Updating price…
Product and service information
FR Rated Panels
Fire-resistant ACM panels meet building codes for exterior applications.
Lead Times
Availability and lead times are confirmed with your final quote based on project size, finish selection, and delivery location.
Cut-to-Length
Custom lengths from 12 in to 300 in. Specify your size when configuring.
Nationwide Shipping
We ship across the US. Delivery options and pricing provided with your quote.
